对比度1000:1 三星新推740BX和940BX

0 2006-07-25 10:10:11 蜂鸟网作者： [合作]

日前，三星新推出了两款显示器——17英寸的SyncMaster 740BX和19英寸的SyncMaster 940BX。这两款显示器主要针对商用市场。除面板大小不一样外，这两款显示器采用了相同的参数： 1280x1024像素的分辨率，1000:1的对比度和5ms的响应时间。接口方面，他们有拥有15针D-sub和DVI接口。740BX和940BX显示器的高度可调，底座可以旋转，且支持VESA 75mm壁挂标准。

[#img_715753_no_0_Black#]
SyncMaster 740BX和SyncMaster 940BX

940BX	740BX
Panel	Viewable Area	19"	17"
	Pixel Pitch	0.294	0.264
	Brightness (typical)	300 cd/m²	300 cd/m²
	Contrast Ratio (typical)	1000:1	1000:1
	Viewing Angle (H/V)	170°/150°	170°/150°
	Response Time (typical)	5ms	5ms
Frequency	Horizontal Frequency (kHz)	30~81	30~81
Frequency	Vertical Frequency	56-75	56-75
Maximum Resolution		1280x1024	1280x1024
Color Supported		16.2 Mil	16.2 Mil
Signal Input	Input Video Signal	Analog RGB, DVI Digital Link	Analog RGB, DVI Digital Link
	Sync. Type	Separate H/V, Composite, SOG	Separate H/V, Composite, SOG
	Input Connectors	15pin D-sub, DVI-D	15pin D-sub, DVI-D
Plug & Play		DDC 2B	DDC 2B
USB Powered Hub Option		X	X
Mac Compatibility		O	O
Power	On Mode	38 Watts (max.)	38 Watts (max.)
Power	DPMS Mode	<1 Watt	< 1 Watt
Type		Built-in	Built-in
Multimedia Speakers		N/A	N/A
Wall Mount		VESA 75mm	VESA 75mm
TCO		TCO '03	TCO '03
Cabinet Color		Silver, Black	Silver, Black
Dimensions	Set (WHD) (with stand)	16.05x16.06x7.87	14.41x15.39x7.87
	Set (WHD) (w/o stand)	16.05x13.19x2.57	14.41x11.85x2.37
	Packing (WHD)	20.63x16.3x9.25	19.57x15.04x9.25
Weight	Set (lbs.)	12.13	10.36
Weight	Packing (lbs.)	16.98	14.55
Special Features		MagicColor	MagicColor
		MagicBrightII	MagicBrightII
		MagicTune with Asset	MagicTune with Asset5
		Management	Management
		Same Mode (down scaling in UXGA)	Same Mode (down scaling in UXGA)
Stand	Type	HAS (80mm)	HAS (80mm)
Stand	Function	HAS: Height Adjustable & Pivot, Swivel	HAS: Height Adjustable & Pivot, Swivel
Standard	Safety	UL (USA)	UL (USA)
Standard	EMC	FCC (USA)	FCC (USA)
